RAPID SEWER JUNCTION CLAMPS (CBJ)
RAPID SEWER JUNCTION CLAMPS (CBJ)
Our Sewer OB Junction clamps are made from 316 Stainless Steel and are ideally suited for new or damaged property connections on non-pressure sewer pipelines, designed for a permanent sewer branch.
Click button for further information:
LOCKING WASHER PLATE
Stainless steel Type 316. Locks into position for easy tightening of nuts.
LUGS
Stainless steel Type 316. MIG-welded to receiver bar and fully passivized after welding. Leading edge is rounded to prevent them from catching bolt bars during installation.
SHELL
Stainless steel Type 316. 2B finish. Fully passivized after welding
BOLTS
Stainless steel Type 316. Thread-rolled for strength and coated to prevent galling. Bolts are MIG-welded to the receiver bar and fully passivized after welding.
NUTS/WASHERS
Stainless steel Type 316.
RECEIVER BARS
Stainless steel Type 316. TIG-welded to shell to form a strong fusion, and fully passivized after welding.
GASKET
Nitrile rubber is specially formulated for water service, gas and oil. Incorporating antioxidant agents to increase shelf life. All gaskets have a gridded design, tapered ends and vulcanized armor plates for easy installation and optimum sealing efficiency. Natural rubber is available on request.
ARMOUR
Stainless steel Type 316. Vulcanized into the gasket at the time of moulding.
TAPPINGS
45 degrees uPVC access coupling secured for solvent welded connections to uPVC pipes.
